Date: 2016-08-05

Here is how to use C++ from Python 2.7

This repository builds a shared object file using cmake. This shared object file maps and binds C++ methods, objects and classes with boost python so they can be used in python after importing the file with import libpyapi_wrapper_ext

I plan to use this repository for integrating a new third-party API that is distributed only in C++.

GitHub Repository: https://github.com/jay-johnson/python-that-runs-c-plus-plus

How to run C++ methods from Python

Here is the python demo code:

#!/usr/bin/python

# Import the PyAPI Wrapper shared object file (extension)
import libpyapi_wrapper_ext

# Pass python variables through the method
some_test_int = 7
some_test_str = "This is how to setup Python to call a C++ API"

# call C++ Wrapper demo method
print "----------------------------"
print "Running C++ demo method from Python"
print libpyapi_wrapper_ext.demo_print_method(some_test_int, some_test_str)

print "Trying C++ Class from Python"
api_key     = "ASDFASDFASDF"
api_skey    = "APISECRET"
wrapper     = libpyapi_wrapper_ext.PyAPIWrapper("demoapi", api_key, api_skey)

str_value   = "Passing a string into C++"
print wrapper.perform_api_action(str_value)

How it Works

  1. Import the C++ shared object file

    import libpyapi_wrapper_ext

  2. Call the demo_print_method

    print libpyapi_wrapper_ext.demo_print_method(some_test_int, some_test_str)


    Under the hood, this code calls a C++ method src/lib_pyapi_wrapper_ext.cpp#L24 that is bound by the line:

    def("demo_print_method", demo_print_method);


    Which runs the C++ method below from src/lib_pyapi_wrapper_ext.cpp#L13

    std::string demo_print_method(int test_int, std::string test_string)
    {
        std::stringstream ss;
        ss << " - Testing Conversion Integer(" << test_int << ") String(" << test_string.c_str() << ")" << std::endl;
        return ss.str();
    }

  3. Create a Python-C++ API Object

    This creates a python wrapper object for demoing how to use a C++ API from python. The sample PyAPIWrapper class is defined in the headers/pyapi_wrapper.h

    api_key     = "ASDFASDFASDF"
    api_skey    = "APISECRET"
    wrapper     = libpyapi_wrapper_ext.PyAPIWrapper("demoapi", api_key, api_skey)

  4. Once the wrapper object is instantiated in python, it can invoke methods exposed by the shared object library file src/lib_pyapi_wrapper_ext.cpp#L25. Here is the code for exposing one of the PyAPIWrapper member methods:

    .def("perform_api_action", &PyAPIWrapper::perform_api_action)


    This code binds the PyAPIWrapper::perform_api_action method from the cpp implementation file src/pyapi_wrapper.cpp#L14

Build Steps

  1. Build the C++ wrapper using CMake

    $ cmake .
    -- The C compiler identification is GNU 5.1.1
    -- The CXX compiler identification is GNU 5.1.1
    -- Check for working C compiler: /usr/lib64/ccache/cc
    -- Check for working C compiler: /usr/lib64/ccache/cc -- works
    -- Detecting C compiler ABI info
    -- Detecting C compiler ABI info - done
    -- Detecting C compile features
    -- Detecting C compile features - done
    -- Check for working CXX compiler: /usr/lib64/ccache/c++
    -- Check for working CXX compiler: /usr/lib64/ccache/c++ -- works
    -- Detecting CXX compiler ABI info
    -- Detecting CXX compiler ABI info - done
    -- Detecting CXX compile features
    -- Detecting CXX compile features - done
    -- Boost version: 1.57.0
    -- Found the following Boost libraries:
    --   filesystem
    --   system
    --   date_time
    --   python
    ---- Boost Include:  /usr/include
    ---- Boost Libs:     /usr/lib64/libboost_filesystem.so/usr/lib64/libboost_system.so/usr/lib64/libboost_date_time.so/usr/lib64/libboost_python.so
    -- Found PythonLibs: /usr/lib64/libpython2.7.so (found version "2.7.10")
    ---- Python Include: /usr/include/python2.7
    ---- Python Libs:    /usr/lib64/libpython2.7.so
    -- Found PythonLibs: python2.7 (found version "2.7.10")
    -- Boost version: 1.57.0
    -- Boost version: 1.57.0
    -- Found the following Boost libraries:
    --   python
    -- Configuring done
    -- Generating done
    -- Build files have been written to: <path>

  2. Make it

    $ make -j4
    Scanning dependencies of target pyapi_wrapper_ext
    [ 33%] Building CXX object CMakeFiles/pyapi_wrapper_ext.dir/src/pyapi_wrapper.cpp.o
    [ 66%] Building CXX object CMakeFiles/pyapi_wrapper_ext.dir/src/lib_pyapi_wrapper_ext.cpp.o
    [100%] Linking CXX shared module libpyapi_wrapper_ext.so
    [100%] Built target pyapi_wrapper_ext
    $

  3. Run the demo

    $ ./run_api_demo.py
    ----------------------------
    Running C++ method from Python
     - Testing Conversion Integer(7) String(This is how to setup Python to call a C++ API)

    Trying C++ Class from Python
    PyAPI(demoapi) running PerformAction with String(Passing a string into C++)

    $


Adding Custom Code

  1. Add your own cpp files to the source list found in the CMakeLists.txt
  2. Run cmake .
  3. Run make

License

MIT

Thanks for reading!

Until next time,

Jay
